Standard profile size: 25x25mm. Bespoke options available.
Up to 8 tiers from 80 to 200cm diameters.
Integral LED lighting.
Hanging – Fully adjustable drop height on 1.2mm stainless
steel suspension cables.
Light Source – Hand drawn glass diffusers.
LED lights CRI> 95 ~ 50K hours life.
LED standard color temperature options: 2.4k 2.7k and 3k
(other temperatures available on request)
Power to fixtures: Via suspension cables.
Light Output: decorative lighting element only.
Indicative Lux level available on request.
LED Driver – Triac Dimmable (5% -100%) as standard
all dimming protocols available on request.
Wattage from 30-200W dependent on sizing.
Output Voltage: 24V.
Input Voltage: 110-277V to be specified.
Bespoke options and design service available.
All fittings and installation instructions are provided.
Maintenance
Clean with smooth and dry cloth. Do not use any ammonia
solvents or abrasives. No user serviceable components.
Refer to the instruction manual for detailed cleaning instructions.
Contact CDH for further technical details / downloads:
technicalcamerondesignhouse.com
https://camerondesignhouse.com
