5-column tubular radiators Zehnder Charleston
(The model is made for smoothing)

5 types of radiator:

Vertical radiators

1. Zehnder Charleston CH 5150 (RAL 9016 black)
– 184 x 1500 x 173 mm – 828 x 1500 x 173 mm
– 276 x 1500 x 173 mm – 920 x 1500 x 173 mm
– 368 x 1500 x 173 mm – 1012 x 1500 x 173 mm
– 460 x 1500 x 173 mm – 1104 x 1500 x 173 mm
– 552 x 1500 x 173 mm – 1196 x 1500 x 173 mm
– 644 x 1500 x 173 mm – 1288 x 1500 x 173 mm
– 736 x 1500 x 173 mm – 1380 x 1500 x 173 mm

2. Zehnder Charleston CH 5180 (Technoline 0325 TL)
– 184 x 1800 x 173 mm – 828 x 1800 x 173 mm
– 276 x 1800 x 173 mm – 920 x 1800 x 173 mm
– 368 x 1800 x 173 mm – 1012 x 1800 x 173 mm
– 460 x 1800 x 173 mm – 1104 x 1800 x 173 mm
– 552 x 1800 x 173 mm – 1196 x 1800 x 173 mm
– 644 x 1800 x 173 mm – 1288 x 1800 x 173 mm
– 736 x 1800 x 173 mm – 1380 x 1800 x 173 mm

Tubular radiators

3. Zehnder Charleston CH 5026 (RAL 9016 white)
– 184 x 260 x 173 mm – 828 x 260 x 173 mm
– 276 x 260 x 173 mm – 920 x 260 x 173 mm
– 368 x 260 x 173 mm – 1012 x 260 x 173 mm
– 460 x 260 x 173 mm – 1104 x 260 x 173 mm
– 552 x 260 x 173 mm – 1196 x 260 x 173 mm
– 644 x 260 x 173 mm – 1288 x 260 x 173 mm
– 736 x 260 x 173 mm – 1380 x 260 x 173 mm

4. Zehnder Charleston CH 5050 (0325 TL)
– 184 x 500 x 173 mm – 828 x 500 x 173 mm
– 276 x 500 x 173 mm – 920 x 500 x 173 mm
– 368 x 500 x 173 mm – 1012 x 500 x 173 mm
– 460 x 500 x 173 mm – 1104 x 500 x 173 mm
– 552 x 500 x 173 mm – 1196 x 500 x 173 mm
– 644 x 500 x 173 mm – 1288 x 500 x 173 mm
– 736 x 500 x 173 mm – 1380 x 500 x 173 mm

5. Zehnder Charleston CH 5060 (Technoline 0328 TL)
– 184 x 600 x 173 mm – 828 x 600 x 173 mm
– 276 x 600 x 173 mm – 920 x 600 x 173 mm
– 368 x 600 x 173 mm – 1012 x 600 x 173 mm
– 460 x 600 x 173 mm – 1104 x 600 x 173 mm
– 552 x 600 x 173 mm – 1196 x 600 x 173 mm
– 644 x 600 x 173 mm – 1288 x 600 x 173 mm
– 736 x 600 x 173 mm – 1380 x 600 x 173 mm

Manufacturer Website: https://zehnder.market/
